Product Details:
|
| Display: | 3 "TFT Color Screen | Resolution: | 960*480 |
|---|---|---|---|
| Pixel: | 2 Million | Depth Of Field: | 3～100mm |
| Field Angle: | 70±2º | Charing Time: | ≤4h |
| Stand-by Time: | ≥300 Mins | WorkingTemperature: | 5℃～40℃ |
| Charger Output: | 5V,2000mA | Blades: | Disposable, T1, T2,T3 |
| Warranty: | 1 Year | OEM MOQ: | ≥ 50 SETS |
| High Light: | T2 Blades Visual Laryngoscope,First Aid Intubation Visual Laryngoscope,3 Disposable Blades Optical Laryngoscope |
||
Technical Feature
| Name | Technical term | Technical Index |
|
Machine |
Display Resolution | 960 x 480 |
| Pixels | 2 million | |
| Camera Resolution | 1280 x 720 | |
| Viewing angle | 70 ± 2 degree | |
| Depth of field | 3~100mm | |
| Host key | Freeze frame, take photo and video | |
| Material | Medical Stainless Steel | |
| Light source | Built-in high power waterproof LED light source | |
| Camera | Dual anti-fog, intubation without blind area | |
| Interface | USB,TF(Hot plug) | |
| Rotate angle | front to back: 135 º, left to right: 275 º | |
| laryngoscope blades | 3 Disposable bladeds, aseptic packaging for single use | |
|
Adapter |
Input | 100 - 240V50/60Hz,0.35A |
| Output | 5V,2000mA, USB output | |
|
Battery |
Charging time | <4h |
| Cycle life of battery | > 800 times | |
| Battery type | lithium ion battery | |
| Battery working time | continues use ≥ 350 mins | |
|
Working Condition |
Environment tem | -5°~ 40°C |
| Relative humidity | ≤80% | |
| atmosphere pressure | 860hpa~1060hpa | |
| internal electric source | lithium ion battery,3.7V | |
| Transport / Storage Condition | Ambient temperature | -40 ~ 55°C |
| Relative humidity | ≤93% |
Main Features :
HYHJ-1330 Disposable visual laryngoscope is hot selling product in Haiye Medical.The machine is novel in design, beautiful in appearance, small in portability, complete in function and simple in use,It is a functional, portable, practical, durable and highly configured medical visual laryngoscope. It is an ideal teaching material tool for the teaching of hospital first aid, clinical use and endotracheal intubation.
HYHJ-Disposable visual laryngoscope has high precision production of all moulds able to service very long.
HYHJ-Disposable visual laryngoscope holds recharable lithium ion battery, can continous use more than 350 mins.
HYHJ-Disposable visual laryngoscope has plenty functions: take photo and video, stop motion, can store and output data.
The 3 minutes opening anti fogging function of HYHJ-Disposable visual laryngoscope there won't be blind zone in trachea intubation.
Three different specifications of HYHJ-Disposable visual laryngoscope's three sizes camera are corresponding to three video laryngoscope blades, the applicable polulation is widely range
3 kinds of medical 3P materials are individually packaged for disposable laryngeal blades to reduce the risk of cross infection
,
Shipping & Packing
Xi’an Haiye Medical Equipment (founded in July 2013) is an comprehensive medical equipment enterprise with high & new technology. Our company is committed to the visual medical fields, our indenpendently R&D vedio laryngoscope are widely used in the medical institutions’anesthesiology, emergency, ICU, pediatric, ambulance, and first aid. Xi’an Haiye always focus on the product quality mangement system, and has attained the ISO13485, ISO9001, and Europe Union CE and U.S.FDA certificate in 2018. Our vedio laryngoscope has export to many countries and regions, such as: U.S., Middle East, Australia, Korea, Russia, Pakistan...
,
Welcome to inquiry if you have any interests!
OEM order is acceptable.
