Product Details:
|
| Product Name: | Video Laryngoscope | Resolution: | 960x480 |
|---|---|---|---|
| Pixel: | 2 Million | Depth Of Field: | 3～100mm |
| Field Angle: | 70±2º | Battery Life: | Recharge＞800times |
| Display: | 3"TFT Color Display | Atmospheric Pressure: | 860hpa～1060hpa |
| Charger Output: | 5V, 2000mA | Charger Input: | 100～240V，50/60Hz,0.35A |
| High Light: | 3.0 Inch Screen Video Laryngoscope,One Time Use Blades Video Laryngoscope,Asepsis Packing Medical Surgical Endoscope |
||
3.0 inch Screen Clarity high practiability Video Laryngoscope with Asepsis Packing One Time Use blades
With photography, video, freeze frame and other functions, and can be stored and exported;
Unique dual anti-fog function, immediately out of the box, no need to preheat, intubation without blind area;
Standard equipped with three different types of cameras, suitable for three different laryngoscope, suitable for different people.
Disposable packaging sterilization of laryngoscope tablets to prevent cross infection; Mature and reliable electronic scheme with complete functions and HD digital camera system, with 3 "TFT color display screen, the effect of restoration is good.
HYHJ-1320 has 3 different sizes of carema for clients to choose, which can suit for various oral structures; the large carema is for adult, medium for children while the small for the newborns. Each camera system has its own disposable laryngoscope blade to match with:
Large carema: HYHJ-1320-T1
Medium carema: HYHJ-1320-T2
Small carema: HYHJ-1320-T3
Technical feature of HYHJ-1320 video laryngosccope
| Name | Technical term | Technical Index |
|
Machine |
Display Resolution | 960 x 480 |
| Pixels | 2 million | |
| Camera Resolution | 1280 x 720 | |
| Viewing angle | 70 ± 2 degree | |
| Depth of field | 3~100mm | |
| Host key | Freeze frame, take photo and video | |
| Material | Medical Stainless Steel | |
| Light source | Built-in high power waterproof LED light source | |
| Camera | Dual anti-fog, intubation without blind area | |
| Interface | USB,TF(Hot plug) | |
| Rotate angle | front to back: 135 º, left to right: 275 º | |
| laryngoscope blades | 3 disposable blades suit for different oral structure | |
|
Powder Adapter |
Input | 100 - 240V50/60Hz,0.35A |
| Output | 5V,2000mA, USB output | |
|
Battery |
Charging time | <4h |
| Cycle life of battery | > 800 times | |
| Battery type | lithium ion battery | |
| Battery working time | continous use ≥ 350 mins | |
|
Working Condition |
Environment tem | -5°~ 40°C |
| Relative humidity | ≤80% | |
| atmosphere pressure | 860hpa~1060hpa | |
| internal electric source | lithium ion battery,3.7V | |
| Transport / Storage Condition | Ambient temperature | -40 ~ 55°C |
| Relative humidity | ≤93% |
Parameters of laryngoscope
1. Vertical distance from the laryngoscope camera to the front of blade:
Large: ≤ 35mm, medium: ≤ 32mm; small: ≤ 28mm
2. Blade length:
Large: 119mm, medium: 95mm; small: 78mm
3. Blades thickness(camera position):
Large/ Medium/ Small: ≤ 10mm
4. Blades angle(degree):
Large: 41, medium: 35; small: 19
Welcome to inquiry if you have any interests!
OEM order is acceptable.
