CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View

Certification
China Xian Haiye Medical Equipment Co.,Ltd certification
China Xian Haiye Medical Equipment Co.,Ltd certification
I'm Online Chat Now

CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View

CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View
CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View

Large Image :  CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View

Product Details:
Place of Origin: China
Brand Name: Haiye
Certification: CE ,ISO13485
Model Number: HYHJ-1330
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD1000-1500 USD/Set
Packaging Details: Carton
Delivery Time: 5-7 days after your payment
Payment Terms: L/C, T/T, D/P, T/T
Supply Ability: 1000 set

CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View

Description
Product Name: Video Laryngoscope Screen: 3.0 Inch
Pixel: 2 Million Material: Stainless Steel
Rechareable Battery: Rechargeable Lithium Battery Display Front And Back Rotation Angle: 0-175
Display Left And Right Rotation Angle: 0-275 Illuminance: >3000LUX
Image/ Video Function: YES Battery Capacity: 3400mA
Cycle Life Of Battery: >600 TIMES Charging Port: Micro USB
High Light:

CMOS Rigid Video Laryngoscope

,

Full View Rigid Video Laryngoscope

,

Reusable Blades Medical Surgical Endoscope

Emergency Medical Device Difficulty Airway Intubation Video Laryngoscope
Video Laryngoscope Product Description

Product Application of reusable video laryngoscope


Routine and difficult tracheal intubation, Could be used for doctors in Anesthesia,

ICU/NICU/CCU, Operating Room, Emergency Rescue, Ambulance,ENT etc.

Clinical training and teaching of tracheal intubation.



*Application range:
Routine and difficult tracheal intubation, Could be used for doctors in Anesthesia,
ICU/NICU/CCU, Operating Room, Emergency Rescue, Ambulance, ENT etc.
Clinical training and teaching of tracheal intubation.



NEW Medical Device Anti-fog Emergency Department Use Video Laryngoscope

**Portable

Light weight, main unit is less than 350g. Disposable blade is vacuum packing. Excellent body design, easy to install or remove. It's ready to use in no time.



Packing and Delivery



Packing Size :400*95*360mm

Package Type :Carton ,Standard Export Packing for Ansthesia Video Laryngoscope With 5 blades.



Specifications for the Video Laryngoscope

PARTS

Description

Technical Index
Machine
Display
3.0 inch LCD
Resolution
960*480 (RGB)
Viewing angle
≥70º
Power
<2W
Display front and back rotation Angle
0 º~175 º
Weight
225g
Camera
Illuminance
≥3000 LUX
Resolution
1280*720 px
Image/Video function
Image/ Video function
Yes
Output
USB output, Easy to storage and establish image/video
Memory type
Micro SD card 8GB-32GB
Battery
Battery Type
Rechargable lithium battery
Capacity
3400mAh
Cycle life of battery
>600 times
Battery working time
>400min
Charging time
<2(hrs)

Charging Port
Micro USB
Power Adapter
Input
100-250V, 50 Hz.
Output
5V1A
Working

Condition
Temperature
-5℃~+50℃
Humidity
10%~90%
Air Pressure
860~1060hpa
Transport / Storage

Condition
Temperature
-10℃~50℃
Humidity
≤93%
Air Pressure
500~1060hpa





**Fordable


The reusable blades can be sterilized by anti-microbial soaking and re-used for 1000 times.
The disposable blades with low cost, with indistinguiashable performance as good as reusable blades





**Durable


The reusable display is intergrated full-view 3" monitor. Screen can resist repeated wiping and normal use wear and tear.

600 minutes ultra-big capacity Li battery, can continually used, life is 3 years.

**High definition


3.0" display with 1280*720 px anti-fog lens, get a high performance visualization capabilities for every intubation.





Product Show



CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 0

CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 1CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 2CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 3

CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 4

CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 5

CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 6



Haiye Video Laryngoscope Exhibation



CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 7

CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 8

CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 9OCMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 10



Our factory



CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 11

CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 12



CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 13



CMOS Rigid Video Laryngoscope With 5 size Reusable Blades 3.0 Inch Full View 14





Certificate



CE ,FDA ,ISO13485
