Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output

Certification
China Xian Haiye Medical Equipment Co.,Ltd certification
China Xian Haiye Medical Equipment Co.,Ltd certification
I'm Online Chat Now

Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output

Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output
Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output
Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output

Large Image :  Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output

Product Details:
Place of Origin: China
Brand Name: HAIYE
Certification: CE ,ISO13485 ,FDA
Model Number: HYHJ-KC
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1000-USD1500/Set
Packaging Details: Carton
Delivery Time: 5-8 days
Payment Terms: L/C, D/P, T/T
Supply Ability: 1000 sets

Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output

Description
Product Name: Video Laryngoscope Screen: 3.0 Inch
Resolution: 960*480 Image /Video: Yes
Storage SD Card: 32 GB Material: Stainless Steel
Blade: Reusable Blade 5 Size Certificate: CE ,ISO13485
Depth Of Field: 3-100mm Field Angle: 70+2
Battery: Recargeable Lithium Battery Batetry Capacity: 3400mA
Battery Cycle Of The Time: >600 Times Battery Working Time: >400 Hrs

Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output



Company Overview:



Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 0






Product of video laryngoscope HYHJ-KC



Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 0






Specifications for the Video Laryngoscope

PARTS
Description
Technical Index
Machine
Screen
3 inch LCD
Resolution
960*480 (RGB)
Viewing angle
≥70º
Power
<2W
Display front and back rotation Angle
0 º~175 º
Weight
225g
Camera
Illuminance
≥3000 LUX
Resolution
1280*720 px
Image/Video function
Image/ Video function
Yes
Output
USB output, Easy to storage and establish image/video
Memory type
Micro SD card 32GB
Battery
Battery Type
Rechargable lithium battery
Capacity
3400mAh
Cycle life of battery
>600 times
Battery working time
>400min
Charging time
<2(hrs)

Charging Port
Micro USB
Power Adapter
Input
100-250V, 50 Hz.
Output
5V1A
Working

Condition
Temperature
-5℃~+50℃
Humidity
10%~90%
Air Pressure
860~1060hpa
Transport / Storage

Condition
Temperature
-10℃~50℃
Humidity
≤93%
Air Pressure
500~1060hpa



Features:

*Anti fog coating on distal lens
*Video/Photo function
*Battery rechargeable
*One button Only, Fast and simple operation
*360 °All sight LCD, no blind spot



Surgical medical equipment Reusable 5 size blades Video Laryngoscope



*Application range:
Routine and difficult tracheal intubation, Could be used for doctors in Anesthesia,
ICU/NICU/CCU, Operating Room, Emergency Rescue, Ambulance, ENT etc.
Clinical training and teaching of tracheal intubation.



NEW Medical Device Anti-fog Emergency Department Use Video Laryngoscope
Advantages

**Portable

Light weight, main unit is less than 350g. Excellent body design, easy to install or remove. It's ready to use in no time.



Packing and Delivery



Packing Size :400*95*360mm

Package Type :Carton ,Standard Export Packing for Ansthesia Video Laryngoscope With 5 blades.



Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 2Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 3Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 4Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 5









Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 6Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 7



Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 8

Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 9

Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 10





Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 11

Certificate





Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 12

Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 13

Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 14

Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 15

Stainless Steel Reusable Blade 5 Size Optical Video Guided Laryngoscope with USB Output 16





Contact us:



HAIYE MEDICAL (Professional Manufacturer of Video Laryngoscope)



FAQ



Q: Are you Manufacturer?
A: We are professional manufacturer of video laryngoscope in China over 5 years, now we mainly produce video laryngoscope with disposable and reusable blade,welcome to visit our factory.


Q: What’s your MOQ and OEM service available?
A: 1 sets as sample can accept, we offer OEM service and print your logo as your requirement.


Q: Can we replace disposable and reusable blade?
A: Main machine is the same, you can match our disposable or reusable freely.


Q: Whats your warranty?
A: We offer 12 months warranty, within warranty change new machine, after warranty only pay produce cost.
