Airway Intubation Disposable Video Laryngoscope All In One CE

Airway Intubation Disposable Video Laryngoscope All In One  CE
Airway Intubation Disposable Video Laryngoscope All In One  CE
Airway Intubation Disposable Video Laryngoscope All In One  CE Airway Intubation Disposable Video Laryngoscope All In One  CE Airway Intubation Disposable Video Laryngoscope All In One  CE Airway Intubation Disposable Video Laryngoscope All In One  CE Airway Intubation Disposable Video Laryngoscope All In One  CE Airway Intubation Disposable Video Laryngoscope All In One  CE

Large Image :  Airway Intubation Disposable Video Laryngoscope All In One CE

Product Details:
Place of Origin: China
Brand Name: Haiye
Certification: ISO CE
Model Number: HYHJ-1330 III
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD 450~899Set
Packaging Details: Anti-drop case with foam protect in carton: 1set/foam protect case/master carton Net weight:1.6KGS Gross Weight:1.9kgs carton size: 260*230*185MM
Delivery Time: 5-7 work days
Payment Terms: T/T
Supply Ability: 1000 set per month

Airway Intubation Disposable Video Laryngoscope All In One CE

Description
Type: Anesthesia Equipments & Accessories Power Source: Electricity
Warranty: 1 Year Instrument Classification: Class II
Pixel: 2 Million Application: ICU/Operating Room /emergency Room
Field Angle: 70±2 Battery Power: 3.7V
After-sale Service: Online Technical Support Battery Life: ≥6hs
High Light:

Medical Airway Intubation Video Laryngoscope

,

Disposable Video Laryngoscope All In One

CE Certificated All-in-one Disposable Video Laryngoscope for Airway Intubation



Company Overview:



Airway Intubation Disposable Video Laryngoscope All In One  CE 0






Product of video laryngoscope HYHJ-1330 III



Production Capacity:



Airway Intubation Disposable Video Laryngoscope All In One  CE 0






Planning for the difficult airway, expected or unexpected, is no longer a challenge when intubating a patient. Whether an adult or a child, with HAIYE ,  you are always prepared for the difficult airway.

HAIYE is designed to enable quick and easy intubation with its display providing a consistent clear real-time view of your patient’s airway. The single-use blades are available in 5 different sizes and offers the choice of two blade types, allowing you to keep your preferred intubation technique.



Get more of the light you want and less of light you don’t. Our video laryngoscopes deliver a high-resolution image powered by the latest advancements in lighting and camera technology, for enhanced airway views



Get the confidence of HAIYE whenever and wherever you need it. Intubate routine and difficult airways with the handheld, portable video laryngoscopy system designed for rapid, first-pass success.



Main Feature of video laryngoscope:
1. 3.0 inch Colorful LCD screen.
2. Camera Resolution: 2 M pixel.
3. Disposable blade and Reusable Blade:Aseptic packaging,strength,comfortable and reliable.
4. Compatible with blade perfect.
5. Video synchronous transmission to big monitor by AV cable.
6. Easy to input the tracheal tube by good view of glottis.
7. More curved blade angle makes it can cope with most difficult airway management.
8. Anti-fog,no need preheating.

Parts Description Technical Index
Machine Screen 3 inch LCD
Resolution 960*480 (RGB)
Viewing angle ≥70º
Power <2W
Display front and back rotation Angle 0 º~175 º
Weight 225g
Camera Illuminance ≥3000 LUX
Resolution 1280*720 px
Image/Video function Image/ Video function Yes
Output USB output, Easy to storage and establish image/video
Memory type Micro SD card 32GB
Battery Battery Type Rechargable lithium battery
Capacity 3400mAh
Cycle life of battery >600 times
Battery working time >400min
Charging time <2(hrs)
Charging Port Micro USB
Power Adapter Input 100-250V, 50 Hz.
Output 5V1A



Advantage of video laryngoscopes
*Anti-fog
*Video/Photo function
*Battery rechargeable
*One button Only, Fast and simple operation

Application of video laryngoscope
1. Clinical endotracheal intubation.
2. Simulation practice
3. Clinical teaching
4. Difficult airway intubation.
Airway Intubation Disposable Video Laryngoscope All In One  CE 2
Airway Intubation Disposable Video Laryngoscope All In One  CE 3

Airway Intubation Disposable Video Laryngoscope All In One  CE 4
FAQ



Q: Are you Manufacturer?
A: We are professional manufacturer of video laryngoscope in China over 5 years, now we mainly produce video laryngoscope with disposable and reusable blade,welcome to visit our factory.


Q: What’s your MOQ and OEM service available?
A: 1 sets as sample can accept, we offer OEM service and print your logo as your requirement.


Q: Can we replace disposable and reusable blade?
A: Main machine is the same, you can match our disposable or reusable freely.


Q: Whats your warranty?
A: We offer 12 months warranty, within warranty change new machine, after warranty only pay produce cost.
