Home ProductsAnesthesia Video Laryngoscope

5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA

Certification
China Xian Haiye Medical Equipment Co.,Ltd certification
China Xian Haiye Medical Equipment Co.,Ltd certification
I'm Online Chat Now

5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA

5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA
5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA

Large Image :  5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA

Product Details:
Place of Origin: China
Brand Name: HAIYE
Certification: CE ,ISO13485,FDA
Model Number: HYHJ-KC
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD1000-USD1500/Set
Packaging Details: Carton
Delivery Time: 5-8days
Payment Terms: L/C, D/P, T/T
Supply Ability: 1000 sets

5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA

Description
Product Name: Video Laryngoscope Screen: 3.0 Inch
Resolution: 960*480 Pixel: 2 Million
Material: Stainless Steel Certificate: CE ,ISO13485 ,FDA
Storage SD Card: 32GB Battery: Rechargeable Lithium Battery
Cycle Life Of Battery: >600 Times Battery Working Time: >400 Hrs
Warranty: 1 Year Battery Capacity: 3400mA
LED Illuminance: 3000lux Depth Of Field: 3-100mm
Field Angle: 70+2
High Light:

5 size blades medical video laryngoscope

,

medical video laryngoscope CE ISO13485 FDA

,

adult laryngoscope CE ISO13485 FDA

Surgical Medical Equipment Reusable 5 size Blades Video Laryngoscope



New Types Anesthesia department Difficulty Airway intubation Reusable Video Laryngoscope



Specifications for the Video Laryngoscope

PARTS
Description
Technical Index
Machine
Screen
3 inch LCD
Resolution
960*480 (RGB)
Viewing angle
≥70º
Power
<2W
Display front and back rotation Angle
0 º~175 º
Weight
225g
Camera
Illuminance
≥3000 LUX
Resolution
1280*720 px
Image/Video function
Image/ Video function
Yes
Output
USB output, Easy to storage and establish image/video
Memory type
Micro SD card 32GB
Battery
Battery Type
Rechargable lithium battery
Capacity
3400mAh
Cycle life of battery
>600 times
Battery working time
>400min
Charging time
<2(hrs)

Charging Port
Micro USB
Power Adapter
Input
100-250V, 50 Hz.
Output
5V1A
Working

Condition
Temperature
-5℃~+50℃
Humidity
10%~90%
Air Pressure
860~1060hpa
Transport / Storage

Condition
Temperature
-10℃~50℃
Humidity
≤93%
Air Pressure
500~1060hpa



Features:

*Anti fog coating on distal lens
*Video/Photo function
*Battery rechargeable
*One button Only, Fast and simple operation
*360 °All sight LCD, no blind spot



Surgical medical equipment Reusable 5 size blades Video Laryngoscope



*Application range:
Routine and difficult tracheal intubation, Could be used for doctors in Anesthesia,
ICU/NICU/CCU, Operating Room, Emergency Rescue, Ambulance, ENT etc.
Clinical training and teaching of tracheal intubation.



NEW Medical Device Anti-fog Emergency Department Use Video Laryngoscope
Advantages

**Portable

Light weight, main unit is less than 350g.  Excellent body design, easy to install or remove. It's ready to use in no time.



Packing and Delivery



Packing Size :400*95*360mm

Package Type :Carton ,Standard Export Packing for Ansthesia Video Laryngoscope With 5 blades.



5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 0









5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 1

5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 2

5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 3

5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 4

5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 5

5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 6

Certificate





5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 7

5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 8

5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 9

5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 10

5 Size Blades Medical Video Adult Laryngoscope CE ISO13485 FDA 11
